Brink Flair 325 Plus - 3 Version; Technical Information

3 Version
3.1 Technical information
Flair 325 (Plus)
Supply voltage [V/Hz] 230V/50Hz
Dimensions (w x h x d) [mm] 750 x 650 x 560
Duct diameter [mm]ø ø160
External diameter condensate discharge
[mm]
ø32
Weight [kg] 37
Filter class ISO Coarse 60% (ISO ePM1 for the air supply oponal)
Fan seng (factory seng) 1 2 3 max
Factory seng [m/ ³h] 50 100 150 250 325
Permissible resistance of duct system [Pa] 2 6 9 24 21 53 59 148 100 250
Rated power (excl. preheater) [W] 6.1 6.6 7.9 10.3 15.1 21.0 46.6 69.1 87.5 144.5
Rated current (excl. preheater) [A] 0.08 0.08 0.09 0.11 0.15 0.21 0.41 0.59 0.73 1.07
Max. rated current (incl. preheater switched
on) [A]
5
Cos j
0.341 0.343 0.389 0.394 0.430 0.439 0.492 0.507 0.521 0.542
Note:
The stated
value in the
circle is the
capacity (in
Watt) per fan
Flow rate [m3/h]
Brink / 7Flair 325 (Plus) 615674-A
Resistance of duct system [Pa]
