26
Step 10
Attach heat shield plate and front
panel to the front of the cart frame
assembly using two M6 X 12mm
bolts with star washers.
Step 11
Attach heat shield plate to the
back of the cart frame assembly
using two M6 X 12mm bolts with
star washers.
Step 12
Place grease cup in middle of hole
in heat shield plate.
Heat Shield Plate
Grease Cup
Heat
Shield
Plate
Heat Shield Plate
To Next Page
