Brinkmann 6330 - Page 31

Step 21
Attach side burner igniter lead wire
to the electrode as illustrated.
Step 22
Place side burner grate over side
burner.
Step 23
Insert grease tray into opening on
backside of grill. Make sure to slide
tray onto tracks as illustrated.
30
Grease Tray
Side Burner Igniter
Lead
Electrode
Side burner grate
MAXIMUM SIDE BURNE
R WEI
GHT = 15 lbs.
