Brinkmann 6430 - Page 30

29
Grease Tray
Step 19
Attach side burner igniter lead wire
to the electrode as illustrated.
Step 20
Place side burner grate over side
burner.
Step 21
Insert grease tray into opening on
backside of grill. Make sure to slide
tray onto tracks as illustrated.
Side Burner Igniter
Lead
Electrode
Side burner grate
MAXIMUM S IDE BURNER WEIGHT = 15 lbs.
