Bottom support - rear (weighted)
Bottom support - front
Bottom shelf assembly
Casters
Leg Caps
Choose a good, cleared assembly
area. Lay cardboard down to
protect grill finish.
CAUTION! Some parts may
contain sharp edges. Wear
protective gloves if necessary.
Step 1
Insert caster into right front leg.
Thread #10 - 24 x 12" bolt through
leg and caster and tighten securely.
Repeat for right back leg.
Step 2
Install leg caps onto ends of left
legs.
Step 3
Attach bottom shelf to bottom
supports using four #10 - 24 x 2"
bolts. The rear bottom support is
taller than the front bottom support
and weighted. Attach bottom
supports to legs using four
#10 - 24 X 12" bolts.
22
