24
Step 6
With the help of a friend, place the
grill body assembly on top of the
assembled cart frame as illustrated.
WARNING: Use caution when lifting
or moving your grill to
prevent strains and back
injuries. Moving your grill
may require the help of
an additional person.
Step 7
Attach grill body assembly to cart
frame using eight #10 - 24 x 12"
bolts, as illustrated.
Step 8
Attach 4" - 20 x 1" bolt and spacer
to legs at the top hole on all four
legs, as illustrated below.
Hang side table over spacers in top
holes. Place spacers on bottom
screws. Insert bolts through bottom
holes in side tables and into legs.
Bolt
Spacer
Leg
To Next Page
