999-00451
Installation Instructions
Box Contents
Mounting Screws (2) ---------
Mounting Plate Screw (1) ------------------
Latch & Strike Screws (4) ---------------------------
Interior Housing Screw (1) -------------------------
Battery Compartment Screws (2) ----------------------
Reinforcement Screws (2) ---
Exterior
Assembly
Interior
Assembly
Need help? Download the ARRAY
™
app or visit www.arraylock.com
for installation videos or call 1-800-850-LOCK (5625).
Rechargeable
Battery
Interior Mounting
Plate
Reinforcement
Plate
Strike
Plate
Dust Box
(Optional)
Drive-in
Collar
USB Cable
Wall Adapter
Square Corner
Face Plate
1
Latch
Screw
Cover
Battery Charging Cradle
Key (2)
Gasket
To Next Page
