COMPONENT VIEW AND REFERENCE LIST
Ref #
BS-26BH
Part #
BS-36BH
Part # Description Qty
1 F-1029-10 F-1029-10 Hopper Support 1
2 F-1030 F-1031 Hopper 1*
3 F-575 F-575 Washer; Thrust, 1/4” 6
4 2M0828SS 2M0828SS Bolt, Hex Stainless, 1/4” x 1-3/4” 6
5 B-4785 B-4785 Nut; Nylon Lock, 1/4” 6
6 F-1013-01 F-1013-01 Axle; Plated 1
7 F-283 F-283 Axle; Bearing 2
8 45M2121P 45M2121P Washer; Flat, 5/8” 8
9 1008774 1008774 Wheel; Pneumatic, Composite Rim 2
10 F-577 F-577 E-Ring; Snap, 5/8” 2
11 F-1009-10 F-1009-10 Plate; Gauge 1
12 F-1010 F-1010-01 Rod; Link 1
13 B-3861 B-3861 Pin; Hitch, 1/2” x 2-1/2” 1
14 10M1032P 10M1032P Bolt, Carriage, 5/16” x 2" 2
15 B-4786 B-4786 Nut; Nylon Lock, 5/16” 7
16 D-146P D-146P Cotter; Hairpin, 1/8” 1
17 R-892-10 R-892-10 Clevis 2
18 50M0416P 50M0416P Pin; Cotter, 1/8” x 1" 1
19 F-436 F-436 Spring, Agitator, SS 1
20 F-365 F-365 O-Ring; I.D. AS-110, 3/8” 1
21 F-1015 F-1015 Transmission Assembly 1
22 F-620 F-620 Cotter; Special Hairpin 1
23 F-892 F-892 Pin; Spring 1
24 F-591 F-591 Driver; Fan 1
25 F-573 F-573 Fan 1
26 30M1000P 30M1000P Nut; Hex, 5/16”-18 2
27 2M1036P-FT 2M1036P-FT Bolt; Hex, 5/16” x 2-1/4” 2
28 F-1023-10 F-1023-10 Tube; Tow 1
29 F-782 F-782 Knob; 4 Prong, Black 1
30 F-781-01 F-781-01 Handle; Stop 1
31 F-1008-10 F-1008-10 Handle; Flow Control 1
32 45M1111P 45M1111P Washer; Flat, 5/16” 8
33 R-618 R-618 Washer; Special 2
34 B-3805 B-3805 Spring 1
35 B-3721 B-3721 Spacer; Latch 1
36 2M1044P 2M1044P Bolt; Hex, 5/16” x 2-3/4” 3
37 R-1882 R-1882 Grip; Flat 1
38 F-1045 F-1045 Bushing; Pivot 4
39 F-787 F-787 Washer; Crvd. Spring-Glv 1
40 B-1002P B-1002P Cotter; Hairpin, .148 Diameter 1
41 11M1012P 11M1012P Bolt; Carriage, 5/16” x 3/4” 1
42 1008378-01 1008378-01 Spacer 2
43 1009191 1009191 Hopper Cover (If equipped) 1
* Reference
the Hopper
Assembly
Part List.
