ASSEMBLY
Assembly Tip
Illustrations on pages 4 & 5 are to-scale.
For faster identication of the hardware during assembly, simply
lay the hardware on top of these illustrations.
Additional info and videos are available on our website: brinly.com
These QR codes
link directly to the
product pages on our
website.
INSTALL HOPPER SUPPORT
TO THE HOPPER
1a. Install six 1/4 x 1-3/4 in.
hex bolts (4), and 1/4 in. thrust
washer (3) through top of
hopper (2) and through support
frame (1), as shown.
1b. Secure bottom of bolt with
1/4 in. lock-nut (5). To avoid
damage to plastic, do not
overtighten hardware.
4
L-1884-F
English Manual
HARDWARE IDENTIFIER
TOOLS
REQUIRED FOR
ASSEMBLY:
• 1/2”Wrench(2)
• 7/16”Wrench(2)
• Pliers
• FlatHeadScrewdrivers
DO NOT RETURN PRODUCT IF YOU ARE MISSING PARTS.
PleaseCall:1(877)728-8224
Illustrationsonthispage
aretoscaleforfaster
identicationofhardware
duringassembly.
E-Rin g;Snap5/8"(x 2).....
F-577
10
Washer;Flat
5/8”(x8)......
45M2121P
8
Washer;Flat
5/16” (x8) ..........
45 M1111P
32
Washer;Thrust
1/4”(x 6) ...........
F- 575
3
Bearing;Axle(x 2) ......
F-283
7
5
Nut:NylonLock
1/4”(x 6)
B- 4785
15
Nut;NylonLock
5/16”( x7)
B- 4786
26
Nut:HexHead
5/16” -18(x 2)
30M1000P
20
O-R ing;
3/8"(x1) 
F-365
23
Pin;
Spring(x1) 
F-892
Washer;Special(x2) .....
R- 618
33
39
Washer;Curved(x1) ......
F-787
*Side View
Bushing;Pivot(x4) .........
F-104 5
38
Spacer(x2) ............
10083 78- 01
42
Figure 1
L-1884-F
5
English Manual
DO NOT RETURN PRODUCT IF YOU ARE MISSING PARTS.
Please Call: 1 (877) 728-8224
HARDWARE IDENTIFIER
Illustrations on this page
are to scale for faster
identication of hardware
during assembly.
Pin; Hitch, 1/2" x 2 1/2" (x1) . . . . . . . . . . . . . . . . . . . . .
B-38 61
13
Bolt; Carriage, 5/16 x 2” (x2) . . . . . . . . . . . . . . . . . . . . . . . . . . .
10M1032 P
14
Hairpin Cotter
(x1) . . . . . . . . . . . . . . . . .
D-14 6P
16
Bolt; Carriage
5/16 x 3/4” (x1) . . . . . . . .
11M1 012 P
41
Bolt; Carriage, 1/4 x 1-3/4” (x6) . . . . . . . . . . . . . . . . . . . . . . .
2M0828SS
4
Bolt; Hex, 5/16 x 2-1/4” (x2) . . . . . . . . . . . . . . . . . . . . . . .
2M1036 P-F T
27
Spring (x1) . . . . . . . . . . .
B-3805
34
Sprin g; Agitator, SS
(x1) . . . . . .
F-436
19
Pin; Cotter
1/8 x 1" (x1) . . . .
50M 0416P
18
Bolt; Hex, 5/16 x 2-3/4” (x3) . . . . . . . . . . . . . . . . . . . . .
2M104 4P
36
Hairpin Cotter; .148" Diameter
(x1) . . . . . . . . . . . . . . . . . . . . . . .
B-100 2P
40
BS-26BH BS-36BH
3
Flat Washer (Nylon)
1/4" Qty. 6
5
Lock Nut; Nylon
1/4" Qty. 6
4
Bolt; Hex
1/4" x 1-3/4" Qty. 6
