5 1018959-B
==================================================================================================
PARTS
English Manual
STOP
Installation Questions? Missing Parts?
Replacement Parts? DON’T GO BACK
TO THE STORE!
Please call our Customer Service
Department, Toll Free: 877-728-8224 or email:
customerservice@brinly.com
Ref
# Part # Description Qty
1 1018925LH-10 Bracket Frame LH Painted 1
2 1018925RH-10 Bracket Frame RH Painted 1
3 1018963 Sprayer Tank, 15 Gal. w/ labels 1
4 1018924-10 Plate Axle Support Painted 2
5 1018930-01 Axle Plated 1
6 B-5691 Spacer, Axle 2
7 45M2121P Washer, Flat 5/8 4
8 1009097 Wheel, 10 x 3 2
9 F-577 E Ring, 5/8" 2
10 1018926-10 Towbar Painted 2
11 R-892-10 Clevis, Painted 2
12 1018929LH-10 Boom Support LH Painted 1
13 1018929RH-10 Boom Support RH Painted 1
14 1018928-10 Brace Cross Painted 1
15 1018927LH-10 Boom LH Painted 1
16 1018927RH-10 Boom RH Painted 1
17 1016887 Pump, 1 gpm 40 psi 1
* 18 B-6511 Clip, Wand Holder 1
* 19 B-6043 Nozzle Body, 90 Degree 2
* 20 B-6041 Nut, Jam, Plastic 2
* 21 B-6040 Strainer, Nozzle 2
* 22 B-6042 Nut, Tip Fitting 2
* 23 1016989 Spray Tips BF 2.0 2
24 1016888 Hose, 3/8" x 8" 1
25 B-6087 Hose, 3/8" x 17" 1
26 B-6035 Hose, 3/8" x 22" 3
27 B-6033 Hose, 3/8” x 12' 1
* 28 B-6047 Clamp, Hose 12
* 29 B-6598 Adaptor, 1/8 MPT x 3/8" H.B. 1
* 30 B-6597 Strainer, 1/4" NPT 1
* 31 1016549 Male Fitting 1
* 32 B-6512 Tee, Dual Valve 1
* 33 B-6055 Hose Barb 2
* 34 B-6056 Nut, Hose Swivel 2
* 35 B-6054 Washer, Vinyl, 3/4" 2
* 36 B-6045 Hose Barb, Tee, 3/8x3/8 1
37 B-6400 Hand Wand 1
38 1018962 Wire Harness Batt Conn 1
ST-152BH
** = Items in the Spray
Fitting Bag ( 1018945 )
Ref
# Part # Description Qty
39 1018961 Wiring Harness w switch 1
40 B-6028 Cap, Tank (Large Cap) 1
41 B-6578-ASM Cap Assembly (Small Cap) 1
Hardware Bag ( 1018943 )
42 10M1032P Bolt, Carriage 5/16 x 2 2
43 11M0824P Bolt, Carriage 1/4 x 1-1/2 1
44 2M1012P Bolt, Hex Hd 5/16 x 3/4 12
45 B-3861 Pin, Hitch 1/2" x 2-1/2" 1
46 B-4785 Nut, Nylon Lock 1/4-20 1
47 B-4786 Nut, Nylon Lock 5/16-18 14
48 B-5695 Bolt, Hex Fl. Head, 5/16 4
49 D-146P Cotter, Hairpin 1/8", #211 1
50 R-618 Washer, Special 4
+ part #6, Spacer Axle ( 2 )
+ part #7, Flat Washer, 5/8” ( 4 )
+ part #9, E-Ring, 5/8” ( 2 )
Inner Hardware Bag ( 1018944 )
52 1007005 Lock Washer, #10 SS 4
53 1016890 Screw, Round Head, #10 4
54 22M0606P Screw, Round Head, #10 1
55 2M1036P-FT Bolt, Hex Head, 5/16 x 2-1/4 2
56 B-4355 Nut, Whiz Lock, 5/16"-18 6
To Next Page
