A017 GB Issue 04
3
2 Quick Reference (please read relevant section for detail)
This quick reference is intended to allow users to quickly set up the incubator and learn the key features of the
control system. Please read the rest of the instructions to obtain a full understanding of each feature.
DO NOT COVER THE INCUBATOR. FOR INDOOR USE ONLY. THE INCUBATOR MUST BE PLACED
IN AN AREA NOT SUBJECT TO SPLASHES OF WATER OR WET CONDITIONS AND OUT OF REACH
OF ANIMALS AND CHILDREN.
THIS INCUBATOR IS NOT A TOY AND MAY ONLY BE OPERATED BY CHILDREN UNDER ADULT
SUPERVISION.
FOR CONTINUED PROTECTION AGAINST FIRE AND ELECTRIC SHOCK ONLY USE THE POWER
SUPPLY UNIT AS SUPPLIED WITH THE INCUBATOR. Spares are available from Brinsea Products Ltd.
1) Carefully unpack the incubator and pump (section 3)
2) Place the egg disc in the base of the incubator, ribbed side up
3) Assemble the pump tubes (section 4)
4) Insert the pump jack plug into the pump output socket on the back of the control housing
5) Insert the power supply unit jack plug into the power input socket on the back of the control housing
6) Plug the power supply unit into a convenient mains outlet
The incubator will sound its buzzer and start to warm up.
The pump will not run if the incubator is significantly below the set temperature. This is to prevent the
system adding too much water when the top has been opened for inspecting eggs etc.
Water tube
Signal lead
Water pump
roto
