Flow Regulators
This shower valve is supplied with a
5 and 7 litre per minute flow
regulator loose in the box which
must be fitted if the shower valve is
installed in conjunction with an
instantaneous water heater /
combination boiler.
With both flow regulators fitted and
by turning the water heater /
combination boiler to its hottest
setting, will ensure a sufficiently hot
water supply to the shower valve
during winter months (in the UK),
when the mains cold water supply is
at its coldest.
To fit the flow regulators
Remove the inlet elbows ensuring
the filter washer is also removed.
carefully remove the plastic inserts
from the valve inlets and push in the
flow regulators. The green 7 litre per
minute flow regulator must be fitted
to the cold inlet and the yellow 5
litre per minute flow regulator must
be fitted to the hot inlet.
Place the filter washers back into
the elbow nuts and tighten the nuts
fully onto the outlets.
In the event that this shower valve
is not installed with an
instantaneous water heater /
combination boiler, the flow
regulators do not need to be fitted.
Flow
Regulator
Insert
Elbow
Filter
Washer
Prior to Installation
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
13
