1. Loosen the infant car seat
harness by pressing the
harness adjuster release
button and pulling both
harness straps forward.
2. Locate the harness yoke
on the back of the infant
car seat and slide one
harness strap o of the
yoke.
Child Seat Functions
Adjusting the Harness
The infant car seat is assembled with the harness in the
inner loops.
• Inner Loop: For infants
weighing less than 5 kg (11 lbs).
• Outer Loop: For infants
weighing over 5 kg (11 lbs).
IMPORTANT: The harness straps
should be located in the closest
harness height position at or
below the child’s shoulders.
IMPORTANT: Ensure the harness straps are fully secured
on the harness yoke�
Inner Loop
Outer Loop
