Britax B-SAFE GEN2 - Child Seat Functions; Adjusting the Harness

30
BRITAX Child Safety, Ltd.
Adjusting the Harness
1. Loosen the infant car seat
harness by pressing the
harness adjuster release
lever and pulling both
harness straps forward.
Child Seat Functions
2. Locate the harness yoke
on the back of the infant
car seat and slide one
harness strap o of the
yoke.
The infant car seat is assembled with the harness in the
inner loop.
• Inner Loop: For infants
weighing less than 5 kg (11 lbs).
• Outer Loop: For infants
weighing over 5 kg (11 lbs).
IMPORTANT: The harness straps
should be located in the closest
harness height position at or
below the child’s shoulders.
IMPORTANT: Ensure the harness straps are fully secured
on the harness yoke�
Inner Loop
Outer Loop
