31
B-SAFE GEN2 User Guide
3. From the front of the
seat, pull the harness
strap through the cover
and head pad.
NOTE: Do not remove the
comfort pad or chest clip.
4. Ensure that the harness
strap is not twisted and
rethread the harness
strap through the head
pad and then through the
appropriate harness height
slot in the cover and shell.
5. From the back of the seat,
reattach the harness straps
to the harness yoke.
6. Repeat these steps with
the second harness strap
and ensure they are at
the same slot height.
Adjusting the Buckle
• Inner Slot: For infants
weighing less than 5 kg
(11 lbs).
• Outer Slot: For infants
weighing over 5 kg (11 lbs).
Inner Slot
Outer Slot
