51
3. Locate the hip strap retainer under
the cover of the child restraint and
pull away from the seat to loosen.
4. Turn the hip strap retainer
so that the short side will
go through the slot in the
carrier shell.
5. Push the hip strap retainer
through the slot under the
carrier shell, following the
current path of the hip strap.
4
5
3
Top Side
of Seat
Front View
Front View
To Next Page
