Briteq BT-Meteor - Setting DMX Starting Address; DMX Configuration (11 CH + 14 CH Mode)

ENGLISH
USER MANUAL
BRITEQ
®
11/74
BT-METEOR
HOW TO SET THE RIGHT STARTING ADDRESS:
Refer to the previous chapter (DMX-512 address setting) to learn how to set the starting address on this unit.
The starting address of each unit is very important. Unfortunately it is impossible to tell you in this user
manual which starting addresses you have to set because this completely depends on the controller you will
use… So please refer to the user manual of your DMX-controller to find out which starting addresses you
must set.
DMX-CONFIGURATION IN 11CH + 14CH MODE:
11CH
14CH
VALUE
FUNCTION
1
1
000 - 255
Pan
2
000 - 255
Pan Fine (Least significant bit)
2
3
000 - 255
Tilt
4
000 - 255
Tilt Fine (Least significant bit)
5
000 - 255
Pan / Tilt Speed (000 = fast ~ 255 = slow)
3
6
000 - 255
Dimmer (0 to 100%)
4
7
Strobe / Shutter effect
000 - 007
Shutter closed (no output)
008 - 015
Shutter open
016 - 131
Strobe 1 (slow → fast)
132 - 139
Shutter open
140 - 181
Strobe 2: slow open / instant close (slow → fast)
182 - 189
Shutter open
190 - 231
Strobe 3: instant open / slow close (slow → fast)
232 - 239
Shutter open
240 - 247
Strobe 4: random strobe (slow → fast)
248 - 255
Shutter open
5
NORMAL
8
NORMAL
Color wheel
000 - 014
COLOR 1: White (open)
015 - 028
COLOR 2: Red
029 - 042
COLOR 3: Orange
043 - 056
COLOR 4: Yellow
057 - 070
COLOR 5: Green
071 - 084
COLOR 6: Blue
085 - 098
COLOR 7: Magenta
099 - 112
COLOR 8: Light Blue
113 - 127
COLOR 9: Pink
128 - 189
Color wheel turning clockwise (fast → slow)
190 - 193
Color wheel stops turning
194 - 255
Color wheel turning counter clockwise (slow → fast)
5
SPLIT
COLOR
8
SPLIT
COLOR
Color wheel
000 - 007
COLOR 1: White (open)
008 - 014
COLOR 1 + 2
015 - 022
COLOR 2: Red
023 - 029
COLOR 2 + 3
030 - 037
COLOR 3: Orange
038 - 044
COLOR 3 + 4
045 - 052
COLOR 4: Yellow
053 - 059
COLOR 4 + 5
060 - 067
COLOR 5: Green
068 - 074
COLOR 5 + 6
075 - 082
COLOR 6: Blue
083 - 089
COLOR 6 + 7
090 - 097
COLOR 7: Magenta
098 - 104
COLOR 7 + 8
105 - 112
COLOR 8: Light Blue
113 - 119
COLOR 8 + 9
