Broadcast Tools, Inc.
SM-6 Programmable Stereo Mixer
Installation and Operation Manual
SM-6 Programmable Stereo Mixer
Page 3
PRODUCT DESCRIPTION
The SM-6 Programmable Stereo Mixer electronically mixes up to 6 balanced
stereo inputs into one balanced stereo output. A jumper is provided to sum the output
into monaural. Due to the low noise and hi slew rate op-amps employed, distortion
and noise are almost non-existent and in no way changes the quality of the signal it is
mixing oe switching.
FRONT PANEL DESCRIPTION
Source Switches
Each switch represents an input to be mixed to the mixers output. The
switches are highly reliable switches, which will give the user years of
dependable service. To select a input, simply push in on the desired channel
switch. To deselect a channel, press the switch again. A power LED indicates
when power is applied to the unit
FUNCTIONAL DESCRIPTION - REAR PANEL CONNECTIONS
The rear panel contains all the input and output connectors. Signal inputs
and outputs are routed through pluggable screw terminals.
Power
Power is supplied by a 2.1mm power connector that plugs in the unit and
a 16 to 18 volt AC wall transformer that connects to a 120 Vac 50-60 Hz power
source.
 Note: 220 Vac 50-60 Hz wall transformer is OPTIONAL
Signal Connector
Pluggable screw terminals provide connection of signal (audio) sources.
