Broadcast SM-6 - Technical Specifications

Broadcast Tools, Inc.
SM-6 Programmable Stereo Mixer
Installation and Operation Manual
SM-6 Programmable Stereo Mixer
Page 6
SPECIFICATIONS
INPUT LEVELS: Max, + 27dbu, Stereo balanced, bridging. > 20k Ω.
OUTPUT LEVELS: Max + 27 dbu, Stereo balanced, @ 100 Ω.
GAIN: 15db.
FREQ RESPONSE: 20 to 20 Khz; + .25 dB / 20 to 30 Khz; + .5 dB
SIGNAL/NOISE RATIO: >85 dB nominal, unweighted, below +4dbu.
DISTORTION: Less than 0.01% THD at + 27dbu.
CROSSTALK: Better than -85 dB @ 1khz / -65 db @ 10 khz from
adjacent off channel.
MIX INPUT: Unbalanced summing inputs @ 10k Ω, 0 dbu.
OPERATION CONTROL: Front Panel - Push-On / Push-Off switches
INTERFACING: Removable screw terminals
POWER REQUIREMENTS: 16 to 18 Vac @ 500 ma. 120 Vac 50-60 Hz wall
Transformer. 240 Vac 50-60 Hz optional
PHYSICAL DIMENSIONS: 8.5" X 1.75" X 6.0" (WHD)
MOUNTING: Optional RM-1 rack shelf (1 RU)
Optional FP-1 filler panel
WEIGHT: 3.0 lb.
SHIPPING WEIGHT: 4.0 lb.
