INSTALLATION
The SM-6 Programmable Stereo Mixer is very simple to install. The signal inputs
and outputs are connected via wire captive terminal strips.
Installation of the SM-6 Programmable Stereo Mixer consists of five steps:
1. Inspect the unit
2. Bench test
3. Mount the unit
4. Connect your equipment
5. Label the Designation Strip
Step 1: Inspect the Unit
Please examine your SM-6 Programmable Stereo Mixer carefully for any
damage that may have been sustained during shipping. If any is noted, please
notify the shipper immediately. Retain the packaging for inspection by the
shipper. The package should contain the SM-6 Programmable Stereo Mixer,
16 volt ac @ 600ma wall power transformer and this manual.
Step 2: Bench Test
Place each unit on a work space and connect power to the unit by
Connecting the 2.1mm power connector into the unit and the wall transformer
into a 120 Vac 50-60 Hz power source. Check to see if the power LED is lit.
Connect a audio source to stereo input one and a monitoring device to the
output. Push in channel ones channel switch. Verify that audio is present.
Repeat the process until each channel’s operation has been verified.
Step 3: Mount the Unit
Mount the unit on a rack shelf, such as the Broadcast Tools RM-1, being
sure to allow adequate airflow for cooling. Mounting brackets are available if
under counter mounting is desire.
