INSTALLATION Continued
Step 4: Connect Your Equipment
The SM-6 Programmable Stereo Mixer interfaces to your equipment (sources and
loads) through the rear panel connectors. Follow the legends for Audio input and
output connections. The SM-6 interfaces to your equipment (sources and loads)
through pluggable rear panel screw terminals. Follow the legends for the desired audio
input and output connections. Follow the legends for the desired audio input and
output connections, which appear on the rear side of the printed circuit board and also
on the layout drawing on the last page of this manual. Remove each screw terminal,
strip each conductor, insert the conductor into the terminal and screw down the capture
screw. The terminals accommodate wire sizes from 16 - 28 AWG solid or stranded
wire.. Rear panel left and right channel input level adjustments may be made. By
removing the top cover, output gain for each channel may be adjusted, R-8 for the left
channel and R-18 for the right. Jumper JP-1 may be inserted to sum the output to
monaural.
Step 5: Label the Designation Strip
The designation strip is provide to write the source descriptions under each
source switch. Apply power via the wall transformer to the unit. Your SM-6
Programmable Stereo Mixer is now fully functional.
