Broadcom 96xx User Guide Broadcom
®
96xx PCIe 4.0, 24G SAS MegaRAID
™
and eHBA Tri-Mode Storage Adapters
Table 9: 9600-24i Adapter PCIe Topology Configuration Combinations
Connector 0 Connector 1 Connector 2
CSW1[8:15] CSW0[8:15] CSW1[0:7]
8 9 10 11 12 13 14 15 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7
x8 x8 x8
x8 x4 x4 x4 x4
x4 x4 x2 x2 x2 x2 x2 x2 x2 x2
x8 x2 x2 x2 x2 x1 x1 x1 x1 x1 x1 x1 x1
x4 x4 x2 x2 x2 x2 Combine with any of the first four
configurations in this column.
x2 x2 x2 x2 x1 x1 x1 x1 x1 x1 x1 x1 Combine with any of the first four
configurations in this column.
x8 x1 x1 x1 x1 x1 x1 x1 x1 Combine with any of the first four
configurations in this column.
x4 x4 x1 x1 x1 x1 x1 x1 x1 x1 Combine with any of the first four
configurations in this column.
x1 x1 x1 x1 x1 x1 x1 x1 x8 Combine with any of the first four
configurations in this column.
x4 x4 x8 Combine with any of the first four
configurations in this column.
x2 x2 x2 x2 x8 Combine with any of the first four
configurations in this column.
x1 x1 x1 x1 x1 x1 x1 x1 x4 x4 Combine with any of the first four
configurations in this column.
x2 x2 x2 x2 x4 x4 Combine with any of the first four
configurations in this column.
x1 x1 x1 x1 x1 x1 x1 x1 x4 x4 Combine with any of the first four
configurations in this column.
Table 10: 9600W-16e Adapter and 9600-16e Adapter PCIe Topology Configuration Combinations
Connector 0 Connector 1 Connector 2 Connector 3
CSW0[12:15] CSW0[8:11] CSW0[4:7] CSW0[0:3]
12 13 14 15 8 9 10 11 4 5 6 7 0 1 2 3
x16
x8 x8
x4 x4 x4 x4
