Specifications: Company 54g Wireless LAN (WLAN) User Manual
Physical Characteristics
Temperature and Humidity Limitations
Power Characteristics
Networking Characteristics
Radio Characteristics
Physical Characteristics
Characteristic Description
Form Factor
Mini PCI specification, May 2002. Type IIIA form factor
Dimensions (length, width)
59.6 mm × 50.95 mm
Temperature and Humidity Limitations
Condition Description
Operating Temperature
0 to 70°C
Operating Humidity
95% maximum (no condensation allowed)
Storage Temperature
–40 to 90°C
Storage Humidity
95% maximum (no condensation allowed)
Power Characteristics
Characteristic
Values
IEEE 802.11g Operation IEEE 802.11b Operation
Doze Mode
40 mA 40 mA
Receive Mode
400 mA 220 mA
Transmit Mode
600 mA 330 mA
Power Supply
3.3 V 3.3 V
