Broadcom 95xx User Guide Broadcom
®
95xx PCIe 4.0 MegaRAID
®
and HBA Tri-Mode Storage Adapters
During the transparent learn cycle, the CacheVault power module consumes up to an additional 6W. The PCIe 3.3V rail
supplies the power for the learn cycle.
HBA Tri-Mode Storage Adapter Power Supply Requirements
The following table describes the typical power consumption of the HBAs.
Table 28: HBA Tri-Mode Storage Adapter Typical Power Consumption
Typical Power (W)
Power Mode
9500-16i 9500-8i 9500-16e 9500-8e
3.3V Supply 0.04 0.02 0.04 0.02
+12V Supply 8.5 5.94 8.70 6.10
Total Power 8.9 5.96 8.74 6.12
Broadcom 95xx-MR-HBA-Tri-Mode-UG104
34
