Broan BKSA1 - Service Parts

INSTALLATION MANUAL SERVICE PARTS
26
KEY
NO.
P
ART NO.DESCRIPTION
QUANTITY
30"
B
LACK
30"
S
TAINLESS
30"
W
HITE
36"
B
LACK
36"
S
TAINLESS
36"
W
HITE
1
S97020029 R
ECIRCULATION COVER PLATE, BLACK (INCLUDING SCREWS)1 1
S97020030 R
ECIRCULATION COVER PLATE, WHITE (INCLUDING SCREWS)1 1
S97020031
R
ECIRCULATION COVER PLATE, STAINLESS STEEL
(INCLUDING SCREWS)
11
2 SR680508 7'' R
OUND DUCT PLATE (INCLUDING SCREWS) 1 1 1111
3 S97020534 3¼”
X 10” DAMPER ASSEMBLY (INCLUDING SCREWS) 1 1 1111
4 S97020408 B
LOWER MOTOR (INCLUDING 4 SCREWS AND 1 CAPACITOR)1 1 1111
5 S97020407 F
ANPELLER (INCLUDING ITEM 6) 1 1 1 1 1 1
6 SR99420635 C
LIP FOR FANPELLER 1 1 1111
7
S99010434-002 G
REASE FILTER-MICRO MESH - TYPE C2 (SET OF 2) 1 1 1
S99010434-003 G
REASE FILTER-MICRO MESH - TYPE D2 (SET OF 2) 1 1 1
8 S97020444 LED
MODULE (PAIR) 1 1 1111
9 S97020445 T
RANSFORMER 24 V 18 VA (WITH SCREWS) 1 1 1111
10
S97020431 C
APTOUCH CONTROL LED, STAINLESS (WITH SCREWS)1 1
S97020432 C
APTOUCH CONTROL LED, WHITE (WITH SCREWS)11
S97020433 C
APTOUCH CONTROL LED, BLACK (WITH SCREWS)1 1
* S97020452 W
IRE HARNESS 1 1 1111
* S97020360
P
ARTS BAG INCLUDING: 4 METAL SCREWS NO. 8-18 X 1/2”,
4
WASHERS, 6 ROUND HEAD NO. 8 X 5/8” WOOD SCREWS,
6
NO. 8 X 1/2” COUNTERSUNK SCREWS
1 1 1111
* S97020466
N
ON-DUCTED FILTER - TYPE XC (SET OF 2)
(
NON-DUCTED INSTALLATION ONLY)
111
* S97020467
N
ON-DUCTED FILTER - TYPE XD (SET OF 2)
(
NON-DUCTED INSTALLATION ONLY)
111
* S99527587 N
ON-DUCTED FILTER CLIP KIT (INCLUDES 4 CLIPS)111
* S97020470 E
ASY INSTALL KIT (INCLUDING HARDWARE)111
BKDB1 SERIES
* ITEM NOT SHOWN.
REPLACEMENT PARTS AND REPAIRS
In order to ensure your unit remains in good working condition, you must use Broan-NuTone LLC or Broan-NuTone Canada ULC
genuine replacement parts only. Broan-NuTone LLC or Broan-NuTone Canada ULC genuine replacement parts are specially designed
for each unit and are manufactured to comply with all the applicable certification standards and maintain a high standard of safety. Any
third party replacement part used may cause serious damage and drastically reduce the performance level of your unit, which will
result in premature failing. Broan-NuTone LLC and Broan-NuTone Canada ULC recommend to contact a certified service depot for all
replacement parts and repairs.
