- 9 -
8. LIGHT BULBS
This hood must use 120 V, 50 W max., type MR16, GU10 shielded halogen lamps. (Purchase separately).
NOTE: The rings must be removed from bottom banel before installing halogen lamps.
WARNING
In order to prevent the risk of personal injury, do not install a lamp identified for use only in
enclosed fixtures.
WARNING
In order to prevent the risk of personal injury, the halogen lamps
must be cooled down before removing them.
8.1 Install the lamps by placing the bulb leads into their grooves in the socket
and gently push upward and turn clockwise until secured.
HE0047
8.3 To remove lamps, gently push upward and turn counterclockwise to
disengage bulb leads from their grooves.
HE0047
8.2 Install trim rings by pushing upward.
HO0034
7. REINSTALL BOTTOM PANEL
Reinstall the bottom panel, using 5 screws saved from step 3,
as shown beside. Reinstall filters.
CAUTION
Remove protective plastic film covering filters before
installing them.
To Next Page
