Broan P12 - Page 5

5
SERVICE PARTS
Model P12
Dual-Wheel Blower / Rough-in Plate
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 97014160 Rough-in Plate Weldment 1
2 99100387 Polyfoam
3 99380605 Barrel Nut 1
4 99150471 Screw, #10-32 x ½ Hex Washer Hd. * 2
5 98003370 Outlet Box Cover 1
6 99100382 Strain Relief 1
7 99440033 Power Cord 1
8 99170245 Screw, #8-18 x 3/8 * 1
‡ 97002302 Parts Bag (Contains (6) #10-16 x 1½ 1
Slotted Pan Head Machine
Screws*)
97014161 Rough-in Kit (complete)
* Standard Hardware. May be purchased locally.
‡ Not shown.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 99020122 Blower Wheel, Clockwise 1
2 99170245 Screw, #8-18 x 3/8 * 12
4 97002321 Scroll, Left 1
7 97014247 Motor Mount 1
8 98003366 Scroll Brace 2
9 97011215 Motor 1
10 97002320 Scroll, Right 1
11 99020121 Blower Wheel, Counterclockwise 1
12 99260477 Nut, ¼-20 Flanged Hex * 4
97014162 Blower Assembly (complete)
* Standard Hardware. May be purchased locally.
