Broan P12 - Service Parts

4
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 97010792 Damper Assembly 1
2 99170245 Screw, #8-18 x 3/8* 4
3 97014276 Rough-in Plate Weldment 1
4 99100387 Polyfoam
5 99380605 Barrel Nut 2
6 99150471 Screw, #10-32 x ½ Hex Washer Head 2
7 98003370 Outlet Box Cover 1
8 99100382 Strain Relief 1
9 99440033 Power Cord 1
10 99260472 Wing Nut 1
‡ 97002302 Parts Bag (Contains (6) #10-16 x 1½ 1
Slotted Pan Head Machine
Screws*)
97014155 Rough-in Kit (complete)
* Standard Hardware. May be purchased locally.
‡ Not shown.
6
10
2
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 99170245 Screw, #8-18 x 3/8 * 6
2 98003365 Mounting Plate 1
3 98008019 Blower Brace 2
4 99260477 Nut, 1/4-20 Flanged Hex * 3
5 97011214 Motor 1
6 99100484 Motor Mount 3
7 97014157 Scroll 1
8 99150536 Screw, 1/4-20 x 5/16 * 3
9 99020145 Blower Wheel 1
97014156 Blower Assembly (complete)
* Standard Hardware. May be purchased locally.
9
SERVICE PARTS
Model P6
Single-Wheel Blower / Rough-in Plate
