broda V4 - Removable Wings; Shoulder Bolsters

13
3.6 22BRemovable Wings
Wings support the Shoulder Bolsters which provide
upper body lateral support. The wings are width and
height adjustable to accommodate various residents.
To Remove the Wing:
-Loosen the knob (1) and pull the wing from the
receptacle.
To Insert the Wing:
- Insert the wing back into the receptacle. Tighten the
knob and ensure the wing is secured in place.
To Adjust the Wing Height:
-Loosen the knob and raise or lower the wing to the
desired position.
-Tighten the knob and ensure the wing is secured in
place.
3.7 23BShoulder Bolsters
The Shoulder Bolsters provide upper torso support,
protection and containment and accommodate
asymmetries in the chair user. Their unique design
allows for proper elbow access to the arm rest. The
Shoulder Bolster is always used in conjunction with the
side wing.
To Attach the Shoulder Bolsters:
-Fit the Shoulder Bolster over the wing.
-Secure with the Velcro strips.
Note: The Shoulder Bolster can be inverted on the wing
in order to provide support to narrower residents.
