12
The energy distribution with different rocker switch settings is as follows (for the maximum energy
display, the power selector 16 must be set to the highest value):
Examples for 1/1 control via switch (1):
Switch Outlet f-stop value Output
Senso A2
Output
Senso A4
Switch (1) = 1/1
Switch (2) = 1/1
Outlet (14.1)
Outlet (14.2)
Outlet (14.3)
10 1200 joule 2400 joule
Switch (1) = 1/1
Switch (2) = 1/2
Outlet (14.1)
Outlet (14.2)
Outlet (14.3)
9.6 900 joule 1800 joule
Switch (1) = 1/1
Switch (2) = 1/4
Outlet (14.1)
Outlet (14.2)
Outlet (14.3)
9.3 750 joule 1500 joule
Examples for 1/2 control via switch (1):
Switch Outlet f-stop value Output
Senso A2
Output
Senso A4
Switch (1) = 1/2
Switch (2) = 1/2
Outlet (14.1)
Outlet (14.2)
Outlet (14.3)
9.0 600 joule 1200 joule
Switch (1) = 1/2
Switch (2) = 1/4
Outlet (14.1)
Outlet (14.2)
Outlet (14.3)
8.6 450 joule 900 joule
Example for 1/4 control via switch (1):
Switch Outlet f-stop value Output
Senso A2
Output
Senso A4
Switch (1) = 1/4
Switch (2) = 1/4
Outlet (14.1)
Outlet (14.2)
Outlet (14.3)
8.0 300 joule 600 joule
Further reductions can be set in 1/10 or full f-stop intervals with the power selector switches (16).
In the symmetry mode, approx. 106 joules is the lowest possible flash energy level with the Senso
A4 (or 53 joules with the Senso A2). This energy can be further reduced when 2 or 3 lamps are
connected. The lamps can be selectively powered via all three outlets (14.1, 14.2, and 14.3).
