BRONKHORST HIGH-TECH B.V.
9.17.017 page 9
1.3 Modul configuration
Module X Sensor
Out
IO
Output
IO
Input
## - # # #
Module
See table Modules, System configuration
*Sensor output signal Code
0 - 5 Vdc A
0 - 10 Vdc B
0 - 20 mA dc (Sinking) C
4 - 20 mA dc (Sinking) D
15 - 20 mA dc E
0 - 20 mA (Sourcing) F
4 - 20 mA (Sourcing) G
FLOW-BUS R
Other/Specify Z
*Not applicable for CEM modules.
I/O output signal Code
0 - 5 Vdc A
0 - 10 Vdc B
0 - 20 mA (Sourcing) C
4 - 20 mA (Sourcing) D
Other/Specify Z
I/O input signal Code
0 - 5 Vdc A
0 - 10 Vdc B
0 - 20 mA (Sourcing) C
4 - 20 mA (Sourcing) D
Other/Specify Z
The temperature control unit offers the ability to set the desired temperature for the heater system of the
CEM. The temperature inside the CEM is monitored with a PT-100 temperature sensor, the signal of which is
being used by the temperature controller to control the adjusted temperature.
Power for the CEM heater is provided for by the R/C module.
For safety reasons the CEM heater W-300 42 Vac is powered with 42 Vac. Because of the high currents
involved, the high power CEM (1000 Watt) has a separate power supply, which is being controlled by the
temperature R/C module, intended for use with this system.
The power for the CEM heater W-300 direct 120 Vac / 230 Vac power supply operation is provided by the
R/C module and does not require a separate power supply.
For detailed information consult manual 9.17.042.
1.4 In/Output signals
If applicable, connection of cables, carrying in- or/and output signals is further explained in the customer
system description.
