OWS Standalone Manual
MA380 - Rev. 2.4
3 PLANNING
3.1 System Components
The following standard modules are used in the Brooks OWS in conjunction with one of the four available
amplifiers:
SUB860, OWS main control module
SUB925, OWS main display board for standalone OWS
8
,
SUB760, Power supply supervision module,
One of the following class D audio amplifiers:
• SUB864, 20W amplifier
• SUB865, 60W amplifier or
• SUB866 , 120W amplifier or
• SUB867, 250W amplifier (special option),
Other options can be used, depending on system requirements and available space in the standard
metal enclosure:
• SUB862, OWS 4 Zone Expansion Termination Board (discontinued)
• SUB999
9
OWS 4 Zone Splitter Board fits 4580 brackets
• PA-1 Brooks Remote Paging Desktop Microphone with BGM / PA enable / disable control
SUB862 is replaced with SUB999 which is about 30% smaller. Its circuitry and features remain unchanged.
The board profile was replicated from 458x series of expansion boards that are used in the Addressable
CIEs so that the mounting brackets CB575 & CB574 can be used for mounting up to 4 boards, see
Figure 6.
3.2 Monitored Inputs and Outputs
The Brooks OWS provides inputs and outputs as listed in Table 2 below, each input or output is
supervised for open or short circuit faults. The inputs or outputs require an End Of Line (EOL) resistor,
47K, 1%, metal film, 1/2W.
Table 2 Supervised Inputs and Outputs
Board Item Terminal
SUB860 OWS Main
Control Board
Warning trigger input TB1, 11 - 12
Bi-polarity strobe output TB2, 3 - 4
Speaker line output TB2 , 13 - 14
Optional SUB999 OWS 4
Zone Splitter Board
Speaker zone 1 output
+ #1 -
Speaker zone 2 output + #2 -
Speaker zone 3 output + #3 -
Speaker zone 4 output + #4 -
Note: Up to 12 x SUB999 Zone Splitter Boards
10
can be added to the OWS depending on the available
space. The above table shows the outputs and terminals for one splitter board.
8
Display board and decal label used in OWS interfaced to CIE is slightly different.
9
SUB999 is a replacement for the previous version SUB862.
10
12 x SUB999 zone splitter board valid only with SUB860 software V2.0
