MANUAL
The user manual contains important
information about the use and settings of
Brose components.
This user manual is based on the standards
and regulations valid in the European Union.
Read the operating instructions, especially the
safety instructions, carefully in the following
chapter before using the Brose Drive System.
Failure to follow the instructions in the user
manual may result in serious injury or damage
to your e-bike. Keep the operating instructions
at hand for further use.
If you pass on the Brose components to third
parties, please always include the respective
user manual.
IMPORTANT INFORMATION
The term «e-bike» used in this user manual
relates to electric bikes, pedelecs and EPAC. It
is an electric bicycle with electronic assistance.
The term «battery» refers equally to mounted
down tube batteries, luggage carrier batteries
and batteries integrated in the frame.
The term battery is used synonymously for
rechargeable energy stores.
1. Safety Advice
› The «Allround» display and control unit
is part of the drive system of your e-bike.
Read and observe the safety advice and
instructions in this manual as well as in
all other instructions enclosed with the
e-bike. Only then is the safe use of the
e-bike possible.
› Failure to comply with or observe the
safety advice and instructions may result
in electric shock, fire and/or serious injury.
› Keep this user manual and all other
enclosed information for future reference.
› Do not open the «Allround» control unit.
Opening the control unit can destroy it and
the warranty claim becomes void.
› Never open the drive unit. This is low
maintenance and must be repaired only by
qualified personnel and only with original
spare parts. The drive unit requires an
inspection by a certified service centre
after 15,000 km.
» This preserves the safety of the drive
unit. Unauthorised opening of the drive
unit voids the warranty claim.
Table of Contents
1. Safety Advice 1
2. Intended Use 3
3. Product Description 3
4. Assembly 5
5. Operation and Control 5
6. Troubleshooting 13
7. Service 15
