Brother DCP-193C Parts Reference List

List1(SCANNER UNIT)
REF No. CODE Q'TY DESCRIPTION SYMBOL REMARKS
1 LX1706001 1 ADF & SCANNER COVER ASSY (SP), MFC295CN
1 LX1714003 1 ADF & SCANNER COVER ASSY (SP), MFC495CW chg
1 LX1714005 1 ADF & SCANNER COVER ASSY (SP), MFC795CW CHG
1-1 LX1707001 1
A
DF & DOCUMENT COVER ASSY
(
SP
),
MFC295CN
1-1 LS6546002 1
A
DF & DOCUMENT COVER ASSY
(
SP
),
MFC495CW
1-1 LS6546003 1
A
DF & DOCUMENT COVER ASSY
(
SP
),
MFC795CW
1-1-1 LS6891001 1 DOCUMENT SPONGE ASSY
(
SP
),
MFC295CN/MFC495CW/MFC795CW
1-1-2 LG6753001 2 DOCUMENT SENSOR PCB ASSY
,
MFC295CN/MFC495CW/MFC795CW
1-1-3 LS4406001 1 DOCUMENT ROLLER HOLDER ASSY
,
MFC295CN/MFC495CW/MFC795CW
1-1-4 087310816 1 TAPTITE CUP B M3X8
,
MFC295CN/MFC495CW/MFC795CW
1-1-5 LS4414001 1
A
DF MOTOR
,
MFC295CN/MFC495CW/MFC795CW
1-1-6 0A5300606 2 SCREW PAN
(
S/P WASHER
)
M3X6
,
MFC295CN/MFC495CW/MFC795CW
1-1-7 LS4691002 1
A
DF UNIT
,
MFC295CN
1-1-7 LS4422002 1
A
DF UNIT
,
MFC495CW
1-1-7 LS4422003 1
A
DF UNIT
,
MFC795CW
1-1-7-1 LS469301
0
1 DOCUMENT STOPPER
,
MFC295CN
1-1-7-1 LS4424011 1 DOCUMENT STOPPER
,
MFC495CW
1-1-7-1 LS442400
7
1 DOCUMENT STOPPER
,
MFC795CW
1-1-7-2 LS5437001 1 SEPARATION PAD AND FILM
,
MFC295CN/MFC495CW/MFC795CW
1-1-7-3 LP1429001 4 EXIT FILM
,
MFC295CN/MFC495CW/MFC795C
W
1-1-8 LS4435001 1
A
DF COVER
,
MFC295CN/MFC495CW/MFC795CW
1-1-9 LS5961001 1 DOCUMENT COVER SUPPORT
,
MFC295CN/MFC495CW/MFC795CW
1-2 LS4442010 2 HINGE
,
MFC295CN
1-2 LS4442011 2 HINGE
,
MFC495CW
1-2 LS4442007 2 HINGE
,
MFC795CW
1-3 LS5965001 1 PAPER JAM INST. LABEL
,
MFC295CN/MFC495CW/MFC795CW
2 LX1551002 1 SCANNER COVER ASSY
(
SP
),
DCP195C/DCP197
C
CHG
2 LX1551005 1 SCANNER COVER ASSY
(
SP
),
DCP365CN
CHG
2
LS6532004 1 SCANNER COVER ASSY
(
SP
),
DCP373CW/DCP375CW/DCP377CW/DCP395CN
DEL
2 LX1551001 1 SCANNER COVER ASSY (SP), DCP373CW/DCP375CW/DCP377CW/DCP395CN/
MFC253CW/MFC255CW/MFC255CWE/MFC257CW
2-1 LS5965001 1 PAPER JAM INST. LABEL,
DCP195C/DCP197C/DCP365CN/DCP373CW/DCP375CW/DCP377CW/DCP395CN/
MFC253CW/MFC255CW/MFC255CWE/MFC257CW
3 LS6545006 1 DOCUMENT COVER ASSY
(
SP
),
DCP195C/DCP197C
3 LS6545005 1 DOCUMENT COVER ASSY
(
SP
),
DCP365CN
3 LS6856002 1 DOCUMENT COVER ASSY
(
SP
),
DCP373CW/DCP375CW/DCP377CW
add
3 LS6856001 1 DOCUMENT COVER ASSY
(
SP
),
DCP395CN
3 LS6545004 1 DOCUMENT COVER ASSY
(
SP
),
MFC253CW/MFC255CW/MFC257CW
3 LX1549001 1 DOCUMENT COVER ASSY
(
SP
),
DCP375CW
/
MFC255CWE
4 LS4537008 2 HINGE
,
DCP195C/DCP197C
4 LS4537011 2 HINGE
,
DCP365CN
4 LS4537007 2 HINGE, DCP373CW/DCP375CW/DCP377CW/DCP395CN/
MFC253CW/MFC255CW/MFC255CWE/MFC257CW
8CAJ06/11/13/15/17/33
36/35/37/41/43/47
DCP195C/DCP197C/DCP365CN
DCP373CW/DCP375CW/DCP377CW/DCP395CN
MFC253CW/MFC255CW/MFC255CWE/MFC257CW
MFC295CN/MFC495CW/MFC795CW
- 2 -
