1.3.4 Set worker switches (WSW) and print worker switch setting data
(function code: 10, 11)
[1] Set worker switches (function code: 10)
<Function>
The worker switches shown in the table below can be used to set the function to satisfy various
requirements. These switch settings can be changed using the keys on the control panel.
The worker switches are factory set to conform to the laws and regulations of the country the
machine is shipped to. Do not change these settings unless necessary.
* Refer to the separate manual for details of worker switches.
WSW No.
Function
WSW No.
Function
WSW01 Dial pulse setting WSW43 Function setting 16
WSW02 Tone signal setting WSW44 Speeding up scanning-1
WSW03 PABX mode setting WSW45 Speeding up scanning-2
WSW04 Transfer facility setting WSW46
PC power monitoring and parallel port settings
WSW05 1st dial tone and busy tone detection WSW47
Switching between high- and full-speed USB
WSW06
[Redial/Pause] key and 2nd dial tone
detection
WSW48
USB setup latency
WSW07 Dial tone setting 1 WSW49 End-of-copying beep
WSW08 Dial tone setting 2 WSW50 SDAA setting
WSW09 Protocol definition 1 WSW51 Function setting 17
WSW10 Protocol definition 2 WSW52 Function setting 18
WSW11 Busy tone setting WSW53 Function setting 19
WSW12 Signal detection condition setting WSW54 Function setting 20
WSW13
Modem setting
WSW55
Interval for regular developing bias value
correction
WSW14 AUTO ANS facility setting WSW56 Function setting 21
WSW15 Redial facility setting WSW57 Function setting 22
WSW16 Function setting 1 WSW58 Function setting 23
WSW17 Function setting 2 WSW59 Function setting 24
WSW18 Function setting 3 WSW60 Function setting 25
WSW19 Transmission speed setting WSW61
Scanning light intensity to judge to be stable 1
WSW20
Overseas communication mode setting
WSW62
Scanning light intensity to judge to be stable 2
WSW21 TAD setting 1 WSW63 Function setting 26
WSW22 ECM and call waiting caller ID WSW64
Language / default paper size setting
WSW23 Communication setting WSW65 Paper support setting
WSW24 TAD setting 2 WSW66 Change of the setting is prohibited
WSW25 TAD setting 3 WSW67 Change of the setting is prohibited
WSW26 Function setting 4 WSW68 Change of the setting is prohibited
WSW27 Function setting 5 WSW69 Change of the setting is prohibited
WSW28 Function setting 6 WSW70 Change of the setting is prohibited
WSW29 Function setting 7 WSW71 Change of the setting is prohibited
WSW30 Function setting 8 WSW72 Change of the setting is prohibited
WSW31 Function setting 9 WSW73 Change of the setting is prohibited
WSW32 Function setting 10 WSW74 ADF stop control
WSW33 Function setting 11 WSW75 Switch back ejection distance
WSW34
Function setting 12
WSW76
Set the limit for the number of documents
to be ejected in reverse order for single-
side scanning from ADF
WSW35
Function setting 13
WSW77
Set the limit for the number of documents
to be ejected in reverse order for duplex
scanning from ADF
WSW36
Function setting 14
WSW78
Recording stop function when the drum
reaches the end of life
WSW37 Function setting 15 WSW79 Function setting 27
WSW38 V.34 transmission settings WSW80 Copying speed control function
WSW39
V.34 transmission speed
WSW81
Changing emulation function enable/
disable setting
WSW40 V.34 modem settings WSW82 AirPrint Icon No. setting
WSW41
ON-duration of the scanning light source
WSW83 Change of the setting is prohibited
WSW42 Internet mail settings WSW84 Change of the setting is prohibited
To Next Page
