Brother DCP-L5500DN Service Manual

5-18
Confidential
<Solenoid and clutch check>
Check the corresponding solenoid and clutch by activating the sensor below.
Both solenoid and clutch can not detect error or fault. They only check if they are functioning.
Sensor operation Solenoid/clutch operation
Change the status of the T1 paper feed sensor from
Paper tray 1 open to Paper tray 1 closed.
The T1 pickup clutch remains ON
for the specified time.
Change the status of the T2LT paper feed sensor from
Paper tray 2 open to Paper tray 2 closed.
The T2LT pickup clutch remains ON
for the specified time.
Change the status of the T2LT paper empty sensor from
No paper to Paper set.
The T2 LT release clutch remains ON
for the specified time.
Change the status of the T3LT paper feed sensor from
Paper tray 3 open to Paper tray 3 closed.
The T3LT pickup clutch remains ON
for the specified time.
Change the status of the T3LT paper empty sensor from
No paper to Paper set.
The T3LT release clutch remains
ON for the specified time.
Change the status of the MP paper empty sensor from
No paper to Paper set.
The MP solenoid remains ON for
the specified time.
Change the status of the registration rear sensor from
No paper to Paper set.
The registration clutch remains ON
for the specified time.
Change the status of the new toner sensor from
Not pressed to Pressed.
The develop clutch remains ON for the
specified time.
Erase Lamp is ON (keep the develop
clutch ON until the new toner sensor
gets pressed)
Change the status of the T2TT paper feed sensor from
TT paper tray 2 open to TT paper tray 2 closed.
The T2TT pickup clutch remains
ON for the specified time.
Change the status of the
T3TT paper feed sensor from
TT paper tray 3 open to TT paper tray 3 closed.
The T3TT pickup clutch remains
ON for the specified time.
Change the status of the
T4TT paper feed sensor from
TT paper tray 4 open to TT paper tray 4 closed.
The T4TT pickup clutch remains
ON for the specified time.
Change the status of the
T5TT paper feed sensor from
TT paper tray 5 open to TT paper tray 5 closed.
The T5TT pickup clutch remains ON
for the specified time.
Change the status of the T3TT paper empty sensor from
No paper to Paper set.
The T3TT release clutch remains
ON for the specified time.
Change the status of the T4TT paper empty sensor from
No paper to Paper set.
The T4TT release clutch remains
ON for the specified time.
Change the status of the T5TT paper empty sensor from
No paper to Paper set.
The T5TT release clutch remains
ON for the specified time.
Note:
• LCD display changes by activating the sensors above. However, it does not affect to the
operation of the solenoid and clutch. If the sensors to operate the solenoid and clutch are
faulty, they are inoperable.
