Brother DCP-L6600DW Instructions For Use

Bedienungsanleitung für / Instructions for use for / Instruction pour utiliser pour / Istruzioni per I´uso per /
Instrucciones de uso para / Návod k obsluze pro / gebruiksaanwijzing voor / podręcznik dla / manual para
Brother DCP-L5500DN/DCP-L6600DW, HL-L5000D/HL-L5100DN/HL-L5100DNT/HL-L5100DNTT/HL-L5200DW/
HL-L6250DN/HL-L6300DW/HL-L6400DW/HL-L6400DWTT, MFC-L5700DN/MFC-L5750DW/MFC-L6800DW etc.
EN
1. Open front cover
2. Take the drum unit together with the catridge in the middle and take it out
of the printer
3. Set the drum unit down in a piece of paper
4. Dissamble the catridge and take it out of the drum unit
5. Unpack the new drum unit
6. Put the catridge into the drum unit and lock the catridge
7. Take the drum unit in the middle and out it into the printer
8. Reset the counter of the drum unit
FOR BROTHER MFC-L6900DW
8.1 press
(screwdriver symbols) → all settings→ device info→ Parts life→ drum
(long press here, short is wrong) to the question „reset drum“ is shown→yes
FOR BROTHER HL-L-5000 D/5100 DN/5200 DW/6250 DN
8.1 Turn on the printer
8.2 Open the front cover
8.3 Press the „OK“ button for 2 seconds
8.4 „Drum Unit“ appears on the display
8.5 Conrm with „OK“
8.6 Press the „arrow up“ (▲)
8.7 Close the cover
FOR BROTHER HL-L-6300 DW/6400 DW/6400 DWT
8.1 Turn on the printer
8.2 The front printer cover must be closed
8.3 Press “X“
8.4 Click on (screwdriver symbol) then on „Machine info“ and on „dur.res.part“
8.5 Press the „drum life“ button
8.6 Keep the button pressed until the message on the display changes
8.7 Press „Yes“
8.8 Press the „Home“ button
FOR BROTHER DCP-L-5500 DN/L-6600 DW
8.1 Turn on the printer
8.2 The front printer cover must be closed
8.3 Press “X“
8.4 Click on (screwdriver symbol) then on „Machine info“ and on „dur.res.part“
8.5 Press the „drum life“ button
8.6 Keep the button pressed until the message on the display changes
8.7 Press „Yes“
8.8 Press the „Home“ button
FOR BROTHER MFC-L-5700 DN/5750 DW/6800 DW/6900 DW/6900 DWT
8.1 Turn on the printer
8.2 The front printer cover must be closed
8.3 Press “X“
8.4 Click on (screwdriver symbol) then on „Machine info“ and on „dur.res.part“
8.5 Press the „drum life“ button
8.6 Keep the button pressed until the message on the display changes
8.7 Press „Yes“
8.8 Press the „Home“ button
Art.-Nr. 812637000023N

Brother DCP-L6600DW Specifications

General

N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	46 ppm
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (color, normal)	9.5 s
Copy speed (black, normal quality, A4)	46 cpm
Scan to	Cloud, E-mail, Image, PC, USB
Scan drivers	ICA, ISIS, SANE, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	A4 / Letter (216 x 297) mm
Output color depth	24 bit
Image formats supported	EXIF, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF, TXT
Faxing	No
Printing colors	Black
Maximum duty cycle	125000 pages per month
Recommended duty cycle	0 - 7500 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, Microsoft XPS, PCL 5e, PCL 6, PDF 1.7
Email protocols	SMTP
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, EAP-FAST, EAP-MD5, EAP-PEAP, EAP-TLS, EAP-TTLS, IPSEC, LEAP, PEAP, SMTP-AUTH, SNMP, SSL/TLS, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Online services supported	Box, Dropbox, Evernote, Facebook, Flickr, Google Drive, OneDrive, OneNote
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, (APIPA IP), WINS / NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR / LPD, Custom Raw Port / Port9100, SMTP client, IPP / IPPS, FTP Client and Server, CIFS client, TELNET Server, SNMPv1 / v2c / v3, HTTP / HTTPS server, TFTP client and server, ICMP, Web Services (Print / scan), SNTP client, LDAP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR / LPD, Custom Raw Port / Port9100, IPP / IPPS, SMTP Client, FTP Client & Server, CIFS Client, TELNET Server, SNMPv1 / v2c, HTTP / HTTPS server, TFTP client & Server, ICMPv6, SNTP client, LDAP, Web Services (Print / scan)
Processor family	ARM Cortex
Sound power level (standby)	57 dB
Sound pressure level (quiet mode)	53 dB
Paper input type	Paper tray
Total input capacity	520 sheets
Total output capacity	250 sheets
Maximum input capacity	1040 sheets
Maximum number of input trays	2
Auto document feeder (ADF) output capacity	80 sheets
Paper tray media types	Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Display	LCD
Control type	Touch
Product color	Gray
Display diagonal	4.8 \
Market positioning	Business
Standard interfaces	Ethernet, NFC, USB 2.0, Wireless LAN
Power consumption (off)	0.04 W
Power consumption (sleep)	8 W
Power consumption (standby)	34 W
Power consumption (PowerSave)	390 W
Power consumption (average operating)	745 W
Energy Star Typical Electricity Consumption (TEC)	2.285 kWh/week
Package depth	526 mm
Package width	599 mm
Package height	659 mm
Package weight	22300 g
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR
Certification	GS Mark
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	427 mm
Width	495 mm
Height	518 mm
