FB-N110, N210
FB-N310
INSTRUCTION MANUAL
BEDIENUNGSANLEITUNG
MANUEL D’INSTRUCTIONS
MANUAL DE INSTRUCCIONES
HIGH SPEED OVERLOCK SEWING MACHINE
HIGH SPEED SAFETY STITCH SEWING MACHINE
Please read this manual before using the machine.
Please keep this manual within easy reach for quick reference.
HOCHLEISTUNGS-ÜBERWENDLINGMASCHINE
HOCHLEISTUNGS-SICHERHEITSNAHTMASCHINE
Bitte vor Gebrauch der Maschine diese Anleitung lesen!
Bitte halten Sie diese Anleitung stets griffbereit zur schnellen Orientierung!
SURJETEUSE GRANDE VITESSE
SURJETEUSE GRANDE VITESSE - POINT SAFETY
Veuillez lire ce manuel avant d’utiliser la machine.
Veuillez garder ce manuel près de vous pour une vérification rapide.
OVERLOCK DE ALTA VELOCIDAD
OVERLOCK CON PUNTADA DE SEGURIDAD
Por favor lea este manual antes de usar la máquina.
Por favor guarde este manual al alcance de la mano para una rápida referencia.

Table of Contents

Other manuals for Brother FB-N110

Preview: Parts Manual
Parts Manual58 pages

Questions and Answers

  • S
    Steven MorrowJul 29, 2025
    Why is the thread breaking on my Brother FB-N110 Sewing Machine?
    • R
      Randy HaynesJul 29, 2025
      Thread breakage can occur due to several reasons. Make sure the needle is correctly installed and the machine is properly threaded. High thread tension could also be the culprit, so check and adjust it as needed. Damage to the looper, needle plate, needle, or needle guard can also cause thread breakage; if any of these parts are damaged, try to fix them with sandpaper or buffing.
  • L
    Lori StoutAug 2, 2025
    What to do if my Brother FB-N110 needle breaks?
    • B
      Benjamin HillAug 2, 2025
      If the needle breaks, make sure you are using a needle and thread that are appropriate for the material you are sewing. Also, check that the needle is installed correctly and that the installation positions of the needle, under looper, and over looper are correct.
  • J
    Janet VaughnAug 7, 2025
    Why does my Brother Sewing Machine skip stitches?
    • M
      michaelallenAug 7, 2025
      Skipping stitches can occur for several reasons. Check the installation positions of the needle, under looper, and over looper. Ensure that the thread tension and threading are correct. Also, check for low thread tension in the double chain stitch looper. If the looper tip is damaged or blunt, correct it with sandpaper or install a new looper.
  • S
    Susan GravesAug 11, 2025
    What to do if seams are not consistent on my Brother FB-N110?
    • S
      Susan MurphyAug 11, 2025
      Inconsistent seams can result from several factors. Start by checking and cleaning the thread path if you notice inconsistent thread tension. Low thread tension or a blunt needle tip can also cause this issue; replace the needle if it's blunt. Also, check for low presser foot pressure and the feed dog height.
  • S
    Sara WhiteAug 15, 2025
    Why does my Brother FB-N110 cause wrinkles?
    • D
      david69Aug 15, 2025
      Wrinkles can appear due to a few reasons. Ensure you are using a needle and thread that match the material. High thread tension can cause wrinkling, so check and adjust it. Also, check for high presser foot pressure, the feed dog height, and the differential feed amount.
  • L
    Lori HeathAug 19, 2025
    What to do if double chain stitching is not possible on my Brother FB-N110?
    • N
      Nancy ShawAug 20, 2025
      If double chain stitching is not working, check the threading. Also, check the needle and looper thread tension, the main feed dog height, the presser foot position, and the double chain stitch looper installation.
  • E
    Edwin GarzaAug 25, 2025
    What to do if the knives cut poorly on my Brother Sewing Machine?
    • M
      marysimmonsAug 25, 2025
      If the knives are not cutting well, check the upper/lower knife overlap and the upper/lower knife installation. Also, check for wear on the upper and lower knives.

Summary

Safety Instructions

Safety Indications and Meanings

Explains the meaning of safety indications and symbols used in the manual and on the machine.

Notes on Safety

Environmental Requirements for Operation

Specifies operating conditions like voltage, humidity, and temperature.

Machine Installation Procedures

Details requirements for professional installation and safety during setup.

2. Installation

Installing the Machine Head

Details the process of installing the semi-submerged machine head onto the work table.

4. Correct Operation

Replacing the Needle

Step-by-step guide on how to remove and insert a new needle correctly.

Threading the Sewing Machine

Detailed diagrams and instructions for threading the machine with different numbers of threads.

Adjusting Thread Tension

Explains how to adjust thread tension for different materials and stitch types.

Adjusting Presser Foot Pressure

Adjusting Stitch Length

Adjusting Differential Feed

How to adjust differential feed for stretch, constant, or gather sewing.

5. Standard Adjustments

Needle Height Adjustment

How to adjust needle height for different models and stitch types.

Under Looper, Movable Needle Guard & Needle Guard F Adjustment

Over Looper Adjustment

Double Chain Stitch Looper & Guards Adjustment (FB-N310)

Presser Foot Adjustment

Feed Dog Height Adjustment

7. Troubleshooting

Brother FB-N110 Specifications

General IconGeneral
BrandBrother
ModelFB-N110
CategorySewing Machine
LanguageEnglish
