Brother HL-1030 - Engine Pcb; Low-Voltage Power Supply Pcb

8. ENGINE PCB PR2002097
REF.NO.
CODE Q'TY DESCRIPTION SYMBOL REMARK
1 LJ4178001 1 ENGINE PCB ASSY A, 1240 (SP) B512059-101D VER.CHNG.
1 LJ8157001 1 ENGINE PCB ASSY B, 1030/1240 (SP) B512075-121D
1 LJ4222001 1 ENGINE PCB ASSY A, 1250 (SP) B512059-102D VER.CHNG.
1 LJ8158001 1 ENGINE PCB ASSY B, 1250/1270 (SP) B512059-122C VER.CHNG.
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-151
T/I NO. PR99165 / PR99197 / PR99202 / PR99213 / PR2000016 / PR2000121
9. LOW-VOLTAGE POWER SUPPLY PCB
REF.NO.
CODE Q'TY DESCRIPTION SYMBOL REMARK
1 LG4015001 1 PS PCB ASSY ZLE-B,115V
1 LG4016001 1 PS PCB ASSY ZLE-B,230V
2 UK4426001 1 INLET UNIT, 115V
2 UK4430001 1 INLET UNIT, 230V
3 085320816 1 TAPTITE, BIND S M3X8
4 087320616 1 TAPTITE, CUP S M3X6
5 LJ4756001 1 AC INLET FILM
6 LJ8330001 1 PROTECTION TUBE
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-200/201
T/I NO. PR99188 / PR99189 / PR2000113 / PR2001064 / PR2002097
CAUTION:
1) The new versions of the engine PCB, ENGINE PCB ASSY B, 1240/1030 (LJ8157001) &
ENGINE PCB ASSY B, 1250/1270 (LJ8158001) should be used for ALL HL-1030/1270N
printers and the HL-1240/1250 printers whose serial No. is the following number or later;
HL-1240: J9J211817 - (EXCEPT J9J212235 - J9J217459, J9J219423 - J9J219997)
HL-1250: J9J221758 -
2) The old versions of the engine PCB, ENGINE PCB ASSY A, 1240 (LJ4178001) & ENGINE
PCB ASSY A, 1250 (LJ4222001) should be used for HL-1240/1250 whose serial No. is before
the number above and the numbers in the range of J9J212235 - J9J217459 & J9J219423 -
J9J219997.
3) The old and new versions of the engine PCB are incompatible with each other.
- 13 -
