3. PAPER FEED
REF.NO. CODE Q'TY DESCRIPTION REMARK
1 UL9060001 1 PAPER FEED ROLLER ASSY
2 UL9066001 1 PAPER PICK-UP ROLLER ASSY
3 LJ4499001 1 TR ELECTRODE HELICAL SPRING
4 LJ4843001 1 OUTER CHUTE 1 (SP)
5 UL9070001 1 GEAR 21
6 UL9059001 1 JOINT 5
7 UL9062001 2 BEARING 5
8 UL9069001 1 CONDUCTOR BEARING 5
9 UL9049001 1 REGIST FRONT ACTUATOR add
10 UL9050001 1 REGIST REAR ACTUATOR add
11 UL9051001 1 REGIST REAR ACTUATOR SPRING add
12 UL9053001 2 TRANSFER ARM add
13 UL9052001 2 TRANSFER SPRING add
14 UU2042001 1 ACTUATOR CASSET
*1 ADD
*1 Except for HL-1230/ HL-1440
MODEL HL-1230/1440/1450/1470N/1430 84U-Z31/Z32/Z33/Z34/Z36-040
