11
MacintoshUSB
Windows
®
Macintosh
USB
For USB Interface Cable Users
6
Connect the printer to
your Macintosh and
install the driver
a Remove the label covering the USB interface
connector.
b Connect the USB cable to the USB connector
marked with a symbol, and then connect
the cable to your Macintosh.
c Make sure the printer power switch is on.
d Turn on your Macintosh. Put the supplied CD-
ROM into your CD-ROM drive.
e Double-click the HL5300 icon on your desktop.
Double-click the Start Here icon. Follow the
on-screen instructions.
f Click Install Printer Driver on the menu
screen.
g Click USB cable users and follow the
on-screen instructions. Then, restart your
Macintosh.
h The Brother software will search for the Brother
printer. During this time the following screen
will appear.
IMPORTANT
DO NOT connect the printer to a USB port on
a keyboard or a non-powered USB hub.
Note
Please see the User’s Guide on the CD-ROM to
install the PS driver (Brother’s BR-Script Driver).
To Next Page
