Brother HL-L2361DN

To Next Page

To Previous Page

3-10

Confidential

3 Bottom side of the top cover ASSY

Panel PCB flat cable

Guides

Panel PCB ASSY

(The shape of PCBs may vary

depending on the specification.)

LCD flat cable (LCD models only)

Top side
