Page #227 background imageLoading...
Page #227 background image
Level 1 Level 2 Level 3 Level 4 Descriptions
WLAN WLAN Enable
- - Turn the wireless interface on or off.
Wi-Fi
Direct
Push Button
- - Configure your Wi-Fi Direct network settings
using the one-button push method quickly.
PIN Code
- - Configure your Wi-Fi Direct network settings
using WPS with a PIN code quickly.
Manual
- - Configure your Wi-Fi Direct network settings
manually.
Group Owner
- - Set your machine as the Group Owner.
Device Info. Device
Name
- View your machine's device name.
SSID
- Display the Group Owner's SSID.
IP Address
- Display your machine's IP Address.
Status Info. Status
- Display the Wi-Fi Direct network status.
Signal
- Display the current Wi-Fi Direct network signal
strength.
When your machine acts as Group Owner, the
LCD always displays Strong.
Channel
- Display the channel in use when the Status is
G/O Active or Client Active.
Speed
- Display the connection speed when the Status
is G/O Active or Client Active.
I/F Enable
- - Enable or disable the Wi-Fi Direct connection.
Network
Reset
- - - Restore all network settings of your machine to
the factory settings.
1
On connection to the network, if the machine's ‘Boot Method’ is ‘Auto’ the machine will attempt to set the IP address and Subnet Mask
from a boot server such as DHCP. If a boot server cannot be found, an APIPA IP address will be allocated, such as 169. 254. [001-254].
[000-255]. If the ‘Boot Method’ of the machine is set to ‘Static’ you must manually enter an IP address from the machine's control panel.
[Network] (HL-L2370DN)
Level 1
Level 2 Level 3 Description
TCP/IP Boot Method
- Choose the IP method that best suits your needs.
IP Address
- Enter the IP address.
Subnet Mask
- Enter the Subnet mask.
Gateway
- Enter the Gateway address.
Node Name
- Enter the Node name.
WINS Config
- Select the WINS configuration mode.
WINS Server Primary
Specify the IP address of the primary WINS server.
Secondary
Specify the IP address of the secondary WINS server.
DNS Server Primary
Specify the IP address of the primary DNS server.
Secondary
Specify the IP address of the secondary DNS server.
APIPA
- Allocate the IP address from the link-local address range
automatically
1
.
IPv6
- Enable or disable the IPv6 protocol.
Ethernet
- - Choose the Ethernet link mode.
Wired Status
- - Display the Ethernet link status.
MAC Address
- - Display the MAC address of the machine.
223
