7
1
g Built-in handle
h Spool pin (page 12 and 16)
The spool pin holds the spool of thread.
i Bobbin winder (page 12)
The bobbin winder winds thread onto the bobbin for
use as the lower thread.
j Handwheel
Use the handwheel to manually raise and lower the
needle.
k Main power/sewing light switch (page 10)
Use this switch to turn on and off the main power and
sewing light.
l Foot controller jack/jack
Insert the foot controller plug into the foot controller
jack, which also supplies power to this machine.
m Thread cutter (page 28)
Pass the threads through the thread cutter to cut them.
n Presser foot lever (page 16)
Use the presser foot lever to raise and lower the presser
foot.
o Bobbin winding pre-tension disc/thread guide (page 12
and 16)
The thread guide/bobbin winding pre-tension disc is
used when winding the thread onto the bobbin and
threading the machine.
p Foot controller (page 11)
Use the foot controller to control the sewing speed and
to start and stop sewing.
Part code;
XC7359-021 (110/120V Area),
XC7438-321 (220/240V Area),
XC7456-321 (U.K.),
XE0629-001 (Australia, New Zealand),
XD0852-021 (Korea),
XC7438-321 (Russia)
