Brother MFC-L5700DW Service Manual

5-55
Confidential
RE_JAM:00000000 Paper jams that have occurred at the ejecting section or back
cover
DX_JAM:00000000 Paper jams that have occurred in the duplex tray
POWER:00000375 Total power distribution time (unit: hour)
PWRCNT:00000001 The number of times that the power is turned ON
KTN_CH:0000
The number of times that the toner cartridge has been replaced
*4
DRUM_CH:0000
The number of times that the drum unit has been replaced
*4
FUSR_CH:0000
The number of times that the fuser unit has been replaced
*4
LASR_CH:0000
The number of times that the laser unit has been replaced
*4
PFMP_CH:000 The number of times that the PF kit MP has been replaced
PFK1_CH:000 The number of times that the PF kit 1 has been replaced
PFK2_CH:000 The number of times that the PF kit 2 has been replaced
PFK3_CH:000 The number of times that the PF kit 3 has been replaced
PFK4_CH:000 The number of times that the PF kit 4 has been replaced
PFK5_CH:000 The number of times that the PF kit 5 has been replaced
KTN_PG1:00000000 Pages printed with the current toner cartridge
KTN_PG2:00000000 Pages printed with the previous toner cartridge
WTNR_PG:00000000
The number of pages printed from the waste toner box
SCN_PG:00000000
The number of scanned pages (except Fax and Copy)
ADSX_PG:00000000
ADF single-side scanned pages (duplex scanning models only)
ADDX_PG:00000000
ADF double-side scanned pages (duplex scanning models only)
ADTL_PG:00000000
Total pages of ADSX_PG and ADDX_PG
FB_PG:000000
Total FB scanned pages
ADSX_JAM:000000
Document jams that have occurred on ADF single-side scanning
(duplex scanning models only)
ADDX_JAM:000000
Document jams that have occurred on ADF duplex scanning
(duplex scanning models only)
FXTX_PG The number of faxed pages
COMERR#:00000000
Communication error log (past three errors)
*5
(models with fax only)
KDEV_BIAS:400V Black developing bias voltage value
ENGERR##:000000
Engine error log (last ten errors)
*6
HODN_ER:0000 The number of discharge errors occurred
FUSR_ER:0000 The number of fuser unit errors occurred
MTLK_ER:0000
The number of polygon motor lock errors occurred in the laser scanner
DEVSTATUS__##:00
Log for design analysis
*7
LCD Description

Brother MFC-L5700DW Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	3.7 \
Market positioning	Business
Digital sender	No
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 5c, PCL 5e, PCL 6, PDF 1.3
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	9.2 s
Copy speed (black, normal quality, A4)	42 cpm
Scan to	CIFS, Cloud, E-mail, E-mail Server, FTP, File, OCR, USB
Scan drivers	ICA, ISIS, SANE, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Input color depth	48 bit
Output color depth	24 bit
Input grayscale depth	16 bit
Output grayscale depth	8 bit
Image formats supported	JPEG, JPG, PNG, TIF, TIFF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	DOCX, HTM, HTML, PDF, PPTX, RTF, TXT, XLS, XLSX, XML, XPS
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Cables included	Phone
Bundled software	Nuance PaperPort SE with OCR for Windows, Presto! PageManager with OCR for Mac
Included cartridge capacity (black)	2000 pages
Email protocols	APOP, IMAP4, POP3, SMTP
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA (Auto IP), WINS/NetBIOS Name Resolution, DNS Resolver, mDNS, LLMNR Responder, LPR/LPD, Custom Raw Port/Port 9100, POP3, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS Server, TFTP Client and Server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP, IMAP4
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Envelopes, Legal, Letter
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Auto Document Feeder (ADF) media weight	60 - 105 g/m²
Card reader integrated	-
Sound pressure level (printing)	54 dB
Sustainability certificates	EPEAT Silver, ENERGY STAR
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1248 W
Power consumption (off)	0.03 W
Power consumption (ready)	36 W
Power consumption (sleep)	8.4 W
Power consumption (printing)	630 W
Power consumption (average operating)	- W
Energy Star Typical Electricity Consumption (TEC)	0.567 kWh/week
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	35 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	426.7 mm
Width	434.4 mm
Height	485.1 mm
