Brother MFC-L5700DW Service Manual

5-56
Confidential
*1
01 to 10 will be displayed for "##" in chronological order. Pressing the [OK] or [SET] key
while the machine error log is displayed shows "PGCNT:00000000 (total pages printed at
the time of the error)" on the LCD, and pressing either key again shows "TMP:**.* HUM:***
(TMP: temperature at the time of the error (°C), HUM: humidity at the time of the error (%))"
on the LCD. Pressing either key again returns the LCD display to machine error log.
*2
The serial number can be changed according to the procedures below.
1) While the serial number is displayed, press the [9], [4], [7], and [5] key in this order to
enter the edit mode.
2) Use the keypad to enter the first digit of the serial number. Enter the second digit to the
15th digit similarly.
<Entry method of alphanumeric characters>
See the table below and press the corresponding key until the desired character is
displayed.
3) Press the [SET] or [Mono Start] key. The serial number is saved and the machine
returns to the initial state of maintenance mode.
*3
For models without fax, the LCD displays "TTLLIST:00000000 (List pages printed)".
*4
Pressing the [SET] key while the replacement count by consumables is displayed shows
"DATE_XX:000000 (XX: name of consumables)" and the date of replacement on the LCD.
(Models without RTC does not display the replacement date.) Pressing the key again
displays the number of times that consumables have been replaced on the LCD.
*5
Pressing the [SET] key while the communication error is displayed shows
"DATE:0000000000" and the date of replacement on the LCD. (Models without RTC does
not display the replacement date.) Pressing the key again displays communication errors on
the LCD.
*6
01 to 10 will be displayed for "##" in chronological order. Pressing the [SET] key while the
machine error log is displayed shows "TM:00000 BT:000 (TM: the minutes passed from the
previous error, BT: the number of times that the power is turned ON/OFF) on the LCD.
Pressing either key again returns the LCD display to machine error log.
*7
01 to 10 will be displayed for "##" in chronological order. Pressing the [SET] key while log for
design analysis is displayed shows "PGCNT:00000000 (total pages printed at the time of the
error)" on the LCD. Pressing the either key again returns the LCD display to log for design
analysis.
Keypad Assigned characters
2 2→A→B→C
3 3→D→E→F
4 4→G→H→I
5 5→J→K→L
6 6→M→N→O
7 7→P→Q→R→S
8 8→T→U→V
9 9→W→X→Y→Z

Brother MFC-L5700DW Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	3.7 \
Market positioning	Business
Digital sender	No
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 5c, PCL 5e, PCL 6, PDF 1.3
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	9.2 s
Copy speed (black, normal quality, A4)	42 cpm
Scan to	CIFS, Cloud, E-mail, E-mail Server, FTP, File, OCR, USB
Scan drivers	ICA, ISIS, SANE, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Input color depth	48 bit
Output color depth	24 bit
Input grayscale depth	16 bit
Output grayscale depth	8 bit
Image formats supported	JPEG, JPG, PNG, TIF, TIFF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	DOCX, HTM, HTML, PDF, PPTX, RTF, TXT, XLS, XLSX, XML, XPS
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Cables included	Phone
Bundled software	Nuance PaperPort SE with OCR for Windows, Presto! PageManager with OCR for Mac
Included cartridge capacity (black)	2000 pages
Email protocols	APOP, IMAP4, POP3, SMTP
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA (Auto IP), WINS/NetBIOS Name Resolution, DNS Resolver, mDNS, LLMNR Responder, LPR/LPD, Custom Raw Port/Port 9100, POP3, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS Server, TFTP Client and Server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP, IMAP4
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Envelopes, Legal, Letter
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Auto Document Feeder (ADF) media weight	60 - 105 g/m²
Card reader integrated	-
Sound pressure level (printing)	54 dB
Sustainability certificates	EPEAT Silver, ENERGY STAR
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1248 W
Power consumption (off)	0.03 W
Power consumption (ready)	36 W
Power consumption (sleep)	8.4 W
Power consumption (printing)	630 W
Power consumption (average operating)	- W
Energy Star Typical Electricity Consumption (TEC)	0.567 kWh/week
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	35 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	426.7 mm
Width	434.4 mm
Height	485.1 mm
