Brother MFC-L5700DW Service Manual

2-31
Confidential
Self-Diagnostic Turn the power off,
then on again.
Leave the machine for
15 min.
An error occurred in the fuser unit
when the power switch was turned
ON or sleep mode was released.
6901 2-49
Will automatically
restart within 15
minutes.
Rechecking the error after the
power switch was turned OFF and
then ON again because an error
was detected in the fuser unit.
(This message is displayed for
approximately 15 minutes when
the machine is restarted after error
code 6901 has occurred.)
6902 2-49
Service Error XX Please contact service
engineer.
Failed to authenticate the firmware
for the self test.
ED00 2-81
Failed to authenticate the NVRAM
for the self test.
EE00 2-81
Size Error Specify the correct
paper size for Tray1.
When printing from paper tray 1, a
paper size not supported for paper
tray 1 was specified from the
driver.
9702 2-72
Specify the correct
paper size for Tray2.
When printing from paper tray 2, a
paper size not supported for paper
tray 2 was specified from the
driver.
9703 2-72
Specify the correct
paper size for Tray3.
When printing from paper tray 3, a
paper size not supported for paper
tray 3 was specified from the
driver.
9704 2-72
Specify the correct
paper size for Tray4.
When printing from paper tray 4, a
paper size not supported for paper
tray 4 was specified from the
driver.
9705 2-72
Specify the correct
paper size for Tray5.
When printing from paper tray 5, a
paper size not supported for paper
tray 5 was specified from the
driver.
9706 2-72
Size Error
2-sided
Press [OK].
Specify the correct
paper and load the
same size paper as
the Printer driver
setting.
A tray set to duplex printing-
incompatible size was specified in
duplex printing.
9701 2-72
Specify the correct
paper.
The registration rear sensor
detected that the paper fed was
smaller or larger than the specified
size in duplex printing mode.
8A01 2-65
Error message
Description
Error
codes
Refer
to:
First line Second line

Brother MFC-L5700DW Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	3.7 \
Market positioning	Business
Digital sender	No
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 5c, PCL 5e, PCL 6, PDF 1.3
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	9.2 s
Copy speed (black, normal quality, A4)	42 cpm
Scan to	CIFS, Cloud, E-mail, E-mail Server, FTP, File, OCR, USB
Scan drivers	ICA, ISIS, SANE, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Input color depth	48 bit
Output color depth	24 bit
Input grayscale depth	16 bit
Output grayscale depth	8 bit
Image formats supported	JPEG, JPG, PNG, TIF, TIFF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	DOCX, HTM, HTML, PDF, PPTX, RTF, TXT, XLS, XLSX, XML, XPS
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Cables included	Phone
Bundled software	Nuance PaperPort SE with OCR for Windows, Presto! PageManager with OCR for Mac
Included cartridge capacity (black)	2000 pages
Email protocols	APOP, IMAP4, POP3, SMTP
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA (Auto IP), WINS/NetBIOS Name Resolution, DNS Resolver, mDNS, LLMNR Responder, LPR/LPD, Custom Raw Port/Port 9100, POP3, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS Server, TFTP Client and Server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP, IMAP4
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Envelopes, Legal, Letter
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Auto Document Feeder (ADF) media weight	60 - 105 g/m²
Card reader integrated	-
Sound pressure level (printing)	54 dB
Sustainability certificates	EPEAT Silver, ENERGY STAR
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1248 W
Power consumption (off)	0.03 W
Power consumption (ready)	36 W
Power consumption (sleep)	8.4 W
Power consumption (printing)	630 W
Power consumption (average operating)	- W
Energy Star Typical Electricity Consumption (TEC)	0.567 kWh/week
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	35 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	426.7 mm
Width	434.4 mm
Height	485.1 mm
