Brother MFC-L5700DW Service Manual

2-32
Confidential
Size Mismatch Reload correct paper. Detected that the size of paper set
in the paper tray was over 10 mm
shorter than letter size during
receiving fax data or printing a list
or report.
8E02 2-66
Reload correct paper
in MP Tray, then press
[Retry].
When printing from the MP tray,
the size of paper set in the MP tray
does not match the size specified
by the driver.
9001 2-67
Reload correct paper
in Tray1, then press
[Retry].
When printing from the paper tray
1, the size of paper set in the
paper tray 1 does not match the
size specified by the driver.
9002 2-67
Reload correct paper
in Tray2, then press
[Retry].
When printing from the paper tray
2, the size of paper set in the
paper tray 2 does not match the
size specified by the driver.
9003 2-67
Reload correct paper
in Tray3, then press
[Retry].
When printing from the paper tray
3, the size of paper set in the
paper tray 3 does not match the
size specified by the driver.
9004 2-67
Reload correct paper
in Tray4, then press
[Retry].
When printing from the paper tray
4, the size of paper set in the
paper tray 4 does not match the
size specified by the driver.
9005 2-67
Reload correct paper
in Tray5, then press
[Retry].
When printing from the paper tray
5, the size of paper set in the
paper tray 5 does not match the
size specified by the driver.
9006 2-67
Supplies Toner Low Dot counter or develop roller
counter of the toner is reaching
the upper limit.
4B01 2-45
Drum End Soon. The number of rotations of the
drum unit is reaching the upper
limit.
4000 2-44
Replace Drum The number of rotations of the
drum unit has reached the upper
limit. (Printing does not stop.)
4200 2-44
Too Many Trays Turn the power off and
remove additional
trays.
Detected more LTs than
connectible limit. 6D00 2-50
Touchscreen
initialization failed
Remove any material
which is on the
touchscreen.
An error occurred while initializing
the touch panel. D800 2-79
Unable to
Update:**
Check the firmware
update file and try
again.
Cannot execute USB Memory
Firm UPDATE. --- 4.14.2
Error message
Description
Error
codes
Refer
to:
First line Second line

Brother MFC-L5700DW Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	3.7 \
Market positioning	Business
Digital sender	No
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 5c, PCL 5e, PCL 6, PDF 1.3
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	9.2 s
Copy speed (black, normal quality, A4)	42 cpm
Scan to	CIFS, Cloud, E-mail, E-mail Server, FTP, File, OCR, USB
Scan drivers	ICA, ISIS, SANE, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Input color depth	48 bit
Output color depth	24 bit
Input grayscale depth	16 bit
Output grayscale depth	8 bit
Image formats supported	JPEG, JPG, PNG, TIF, TIFF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	DOCX, HTM, HTML, PDF, PPTX, RTF, TXT, XLS, XLSX, XML, XPS
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Cables included	Phone
Bundled software	Nuance PaperPort SE with OCR for Windows, Presto! PageManager with OCR for Mac
Included cartridge capacity (black)	2000 pages
Email protocols	APOP, IMAP4, POP3, SMTP
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA (Auto IP), WINS/NetBIOS Name Resolution, DNS Resolver, mDNS, LLMNR Responder, LPR/LPD, Custom Raw Port/Port 9100, POP3, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS Server, TFTP Client and Server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP, IMAP4
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Envelopes, Legal, Letter
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Auto Document Feeder (ADF) media weight	60 - 105 g/m²
Card reader integrated	-
Sound pressure level (printing)	54 dB
Sustainability certificates	EPEAT Silver, ENERGY STAR
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1248 W
Power consumption (off)	0.03 W
Power consumption (ready)	36 W
Power consumption (sleep)	8.4 W
Power consumption (printing)	630 W
Power consumption (average operating)	- W
Energy Star Typical Electricity Consumption (TEC)	0.567 kWh/week
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	35 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	426.7 mm
Width	434.4 mm
Height	485.1 mm
