Brother MFC-L5850DW Service Manual

1-7
Confidential
Model MFC-L6750DW MFC-L6800DW MFC-L6900DW MFC-L6902DW
Warm-up
time
From Sleep
mode
Less than 5.7 sec. at 73.4F / 50%RH (23°C / 50%RH) for the U.S.A./
Brazil
Less than 4.7 sec. at 73.4F / 50%RH (23°C / 50%RH) except for the
U.S.A./Brazil
From Power
OFF
 ON
Less than 27 sec. at 73.4F / 50%RH (23°C / 50%RH)
First print
time
From Ready
mode
Less than 7.5 secs at 73.4F (23°C)
From Sleep
mode
Less than 13.2 secs at 73.4F (23°C) for the U.S.A./Brazil
Less than 12.2 secs at 73.4F (23°C) except for the U.S.A./Brazil
Printing speed
(A4/Letter)
Up to 46/48 ppm
(Quiet Mode: Up to 25/26 ppm)
Up to 50/52 ppm
(Quiet Mode: Up to 25/26 ppm)
CPU Cortex-A9
800 MHz
Backup clock Up to 60 hours
Dimensions
(W x D x H)
Carton size 599 x 526 x 762 mm
(23.6 x 20.7
x 30.0 inch)
599 x 526 x 659 mm
(23.6 x 20.7 x
25.9 inch) except
for Italy-CONSIP
599 x 526 x 762 mm
(23.6 x 20.7
x 30.0 inch)
for Italy-CONSIP
599 x 526 x 762 mm
(23.6 x 20.7 x 30.0 inch) except for Oceania
599 x 526 x 659 mm
(23.6 x 20.7 x 25.9 inch) for Oceania
Machine
size
495 x 427 x 518 mm
(19.5 x 16.8 x 20.4 inch)
Weights
with carton 23.3 kg / 51.4 lb 22.6 kg / 49.8 lb
(for the U.S.A.)
22.9 kg / 50.4 lb
(for Europe except
Italy-CONSIP)
23.5 kg / 51.8 lb
(for Italy-CONSIP)
23.5 kg / 51.8 lb
(for the U.S.A.)
23.4 kg / 51.6 lb
(for Latin America)
23.8 kg / 52.4 lb
(for Europe)
22.5 kg / 49.7 lb
(for Oceania)
23.7 kg / 52.3 lb
(for Asia)
23.4 kg / 51.6 lb
without
carton,
with toner/
drum
18.8 kg / 41.4 lb 18.8 kg / 41.5 lb
(for the U.S.A.)
18.9 kg / 41.6 lb
(for Europe except
Italy-CONSIP)
19.0 kg / 41.9 lb
(for Italy-CONSIP)
19.0 kg / 41.9 lb
(for the U.S.A./
Latin America)
19.0 kg / 42.0 lb
(for Europe)
18.9 kg / 41.6 lb
(for Oceania)
19.1 kg / 42.2 lb
(for Asia)
19.0 kg / 41.9 lb
without
carton and
toner/drum
17.0 kg / 37.5 lb 17.2 kg / 37.9 lb
Specifications are subject to change without notice.

Brother MFC-L5850DW Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	9.2 s
Copy speed (black, normal quality, A4)	42 cpm
Scan to	CIFS, Cloud, E-mail, E-mail Server, FTP, File, OCR, USB
Scan drivers	ICA, ISIS, SANE, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Input color depth	48 bit
Output color depth	24 bit
Scan speed (black)	28 ppm
Scan speed (color)	20 ppm
Input grayscale depth	16 bit
Image formats supported	JPEG, JPG, PNG, TIF, TIFF
Maximum scan resolution	19200 x 19200 DPI
Duplex scan speed (black)	56 ppm
Duplex scan speed (color)	34 ppm
Document formats supported	DOCX, HTM, HTML, PDF, PPTX, RTF, TXT, XLS, XLSX, XML, XPS
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	300
Printing colors	Black
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 5c, PCL 5e, PCL 6, PDF 1.3
Display	TFT
Control type	Touch
Display diagonal	3.7 \
Market positioning	Business
Email protocols	APOP, IMAP4, POP3, SMTP
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Near Field Communication (NFC)	No
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA (Auto IP), WINS/NetBIOS Name Resolution, DNS Resolver, mDNS, LLMNR Responder, LPR/LPD, Custom Raw Port/Port 9100, POP3, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS Server, TFTP Client and Server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP, IMAP4
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, POP3, SMTP Client, FTP Client y Server, CIFS Client, TELNET Server, SNMPv1/v2c, HTTP/HTTPS server, TFTP client y server, ICMPv6, SNTP Client, LDAP, Web Services (Print/Scan), IMAP4
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	70 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Envelopes, Legal, Letter
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Auto Document Feeder (ADF) media weight	60 - 105 g/m²
Package depth	525.8 mm
Package width	599.4 mm
Package height	629.9 mm
Package weight	20865 g
Quantity per pack	1 pc(s)
Recommended monthly print volume	3500 pages
Card reader integrated	-
Sound pressure level (printing)	55 dB
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1248 W
Power consumption (off)	0.03 W
Power consumption (ready)	36 W
Power consumption (sleep)	8.4 W
Power consumption (printing)	630 W
Power consumption (average operating)	- W
Energy Star Typical Electricity Consumption (TEC)	0.567 kWh/week
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	35 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Silver, ENERGY STAR
Cables included	Phone
Bundled software	Nuance PaperPort SE with OCR for Windows, Presto! PageManager with OCR for Mac
Included cartridge capacity (black)	3000 pages

Weight and Dimensions

Depth	426.7 mm
Width	495.3 mm
Height	485.1 mm
