ix
Confidential
To use the Machine Safely
Please keep these instructions for later reference and read them before attempting any
maintenance. If you do not follow these safety instructions, there is a possibility of a fire,
electrical shock, burn or suffocation.
WARNING
ELECTRICAL HAZARDS
Failure to follow the warnings in this section may create the risk of an electrical shock. In
addition, you could create an electrical short, which may create the risk of a fire.
There are high voltage electrodes inside the product. Before you access the inside of the
product, including for routine maintenance such as cleaning, make sure you have
unplugged the telephone line cord first (MFC only) and then the power cord from the AC
power outlet, as well as any telephone (RJ-11) (MFC only) or Ethernet (RJ-45) cables
(Network models only) from the product. Never push objects of any kind into this product
through cabinet slots, since they may touch dangerous voltage points or short out parts.
Unplug the power plug regularly to clean it. Use a dry cloth to clean the root of the plug
blades and between the blades. If the power plug is plugged into the outlet over a long
period, dust accumulates around the plug blades, which may cause a short circuit
resulting in a fire.
DO NOT handle the plug with wet hands. Doing this might cause an electrical shock.
Always make sure the plug is fully inserted. DO NOT use the product or handle the cord if
the cord has become worn or frayed.
DO NOT allow this product to come into contact with water.
This product should be connected to an AC power source within the range indicated on
the rating label. DO NOT connect it to a DC power source or inverter.

Table of Contents

Other manuals for Brother MFC-L5900DW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother MFC-L5900DW and is the answer not in the manual?

Brother MFC-L5900DW Specifications

General IconGeneral
Secure printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)44 ppm
Copier resize25 - 400 %
Maximum copy resolution1200 x 600 DPI
N-in-1 copy function (N=)2, 4
Copy speed (black, normal quality, A4)42 cpm
Total input capacity250 sheets
Total output capacity150 sheets
Multi-Purpose tray input capacity50 sheets
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100/1000Base-T(X)
Security algorithms64-bit WEP, 128-bit WEP, 802.1x RADIUS, SSL/TLS, WPA-PSK, WPA2-PSK
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, POP3, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP, IMAP4
Supported network protocols (IPv6)NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, POP3, SMTP Client, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c, HTTP/HTTPS server, TFTP client and server, ICMPv6, SNTP Client, LDAP, Web Services (Print/Scan), IMAP4
Direct printing-
Standard interfacesEthernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity1
Internal memory512 MB
Printing colorsBlack
Maximum duty cycle50000 pages per month
Recommended duty cycle0 - 3500 pages per month
Page description languagesBR-Script 3, Epson FX, PCL 6, PDF 1.7
FaxingMono faxing
Fax memory500 pages
Modem speed33.6 Kbit/s
Fax coding methodsJBIG, JPEG, MH, MMR (Fax coding method), MR
Scan toCloud, FTP, File, Image, OCR, USB
Scanner typeFlatbed & ADF scanner
Input color depth48 bit
Image formats supportedBMP, JPG, MMR, PNG, TIF
Maximum scan resolution19200 x 19200 DPI
Document formats supportedDOCX, PDF, PPTX, XML, XPS
Envelopes sizes6 3/4, 7 3/4, 9, 10
Paper tray media typesBond paper, Labels, Plain paper, Recycled paper
ISO A-series sizes (A0...A9)A4, A5, A6
Multi-purpose tray media typesEnvelopes
Maximum ISO A-series paper sizeA4
Paper tray media weight (imperial)16 - 32 lbs
Multi-Purpose Tray media weight (imperial)16 - 53 lbs
DisplayLCD
Control typeTouch
Display diagonal3.7 \
Market positioningBusiness
AC input voltage120 V
AC input frequency50 - 60 Hz
Power consumption (ready)36 W
Power consumption (sleep)1.6 W
Power consumption (average operating)630 W
Sustainability certificatesENERGY STAR
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)20 - 80 %
Package depth526 mm
Package width599 mm
Package height629 mm
Package weight20900 g
Weight and Dimensions IconWeight and Dimensions
Depth427 mm
Width495 mm
Height486 mm
